DC12V 3key LED Strip Mini RGB Controller

Specification:

1) Item: 3-key Mini RGB LED Controller

2) Input: DC12V

3) Connection mode: Common Anode(+)

4) Working Temperature: -35°C- +75°C

5) Dimension: (about) L42mm x W12mmx3mm

6) Main Keys: MODE; SPEED/BRIGHT; COLOR.

7) Touch keys, you can easily adjust the various modes, speed, and brightness.

8) Used for : LED 3528 5050 RGB Color LED Light Strip

Parameters

Operation

1. Mode Key: Switch to dynamic mode. Press this key to switch among 19 dynamic modes. Keep pressing mode key over one second will switch to demo mode which automatically change mode in a loop.

2. Color Key: Switch to static color mode. Press this key to switch among 20 color modes.

3. Speed/Bright Key(Adjust key): Adjust brightness or speed. At dynamic mode, press this key to playing speed among 5 levels. At static color mode, press this key to change color brightness among 5 levels.
